Using below 3mmauto is fine wires and can break from vibration
auto sizes are bad to use anyways
3mm auto = 1 mmsq
4mm auto = 2mmsq use this as minimum
-- Edited by Woody n Sue on Sunday 18th of March 2018 06:32:01 PM
madaboutled said
06:55 PM Mar 18, 2018
This is a printable PDF that I use as a voltage drop and size gauge when needed. At the bottom is a conversion chart from AWG to Metric.
If you print the page as A4 without re-sizing it, then the conversion chart at the bottom should be reasonably accurate. Note the black dots represent the wire thickness witout the insulation.
thanks Joe, tucked it away as I know Im going to need it one day
chugger said
08:18 PM Mar 25, 2018
group thank you, there are some great resources in this thread
Craig1 said
08:35 PM Mar 25, 2018
Thanks Mad Steve,
If you change orientation to Landscape and increase size to 90% it makes a very readable document, buggers your dot size a bit though, so will laminate both together I think and mark the right size dots 1st. Thanks for that, cheers Craig
This wiring chart might come in handy.
https://www.victronenergy.com/upload/documents/AWG%20to%20Metric%20Conversion%20Chart.pdf
Joe
Cheers
Joe
Gday...
Always good to get info ...
I had this one tucked away...
Cheers - John
wire size chart is absolutely no good if used for high currents with out volt drop chart /calculator.
www.voltagedropcalculator.com.au/
voltdrops allowable
most 3-5 %
solar 0-3 %
Using below 3mmauto is fine wires and can break from vibration
auto sizes are bad to use anyways
3mm auto = 1 mmsq
4mm auto = 2mmsq use this as minimum
I have recently found this one too
www.redarc.com.au/images/uploads/files/wire_gauge_worksheet.pdf
Woody
-- Edited by Woody n Sue on Sunday 18th of March 2018 06:32:01 PM
This is a printable PDF that I use as a voltage drop and size gauge when needed. At the bottom is a conversion chart from AWG to Metric.
If you print the page as A4 without re-sizing it, then the conversion chart at the bottom should be reasonably accurate. Note the black dots represent the wire thickness witout the insulation.
http://madaboutled.com/images/Wire-Guage.pdf
thanks Joe, tucked it away as I know Im going to need it one day
group thank you, there are some great resources in this thread
If you change orientation to Landscape and increase size to 90% it makes a very readable document, buggers your dot size a bit though, so will laminate both together I think and mark the right size dots 1st. Thanks for that, cheers Craig
