We are having trouble with interference in the form of pixelization and sound breakup. I happens when I run the 12 V exhaust fans in the toilet or shower. I could put up with that but I have just recently bought a re-chargeable 8" fan and this also causes the problem whether its running of any power source (240V / 12V) including when running off the internal battery.
Only the fans cause this, air con and other appliances seem to have no detrimental effect.
Any ideas how to fix this problem?
Possum3 said
10:06 PM Jan 7, 2019
It seems the (cheap) 12V motors in bathroom exhaust fans create interference with most TV's using the same 12V system - If you can run the TV on 240V if in caravan park that may relieve the interference.
oldbloke said
10:38 AM Jan 8, 2019
Mmmm, I don't recall if running the TV on 240v fixes the problem. However I would still like it to work OK on 12v anyway.
-- Edited by oldbloke on Tuesday 8th of January 2019 10:39:37 AM
Warren-Pat_01 said
01:11 PM Jan 8, 2019
Neil,
A cheap way could be the addition of a 1microfarad capacitor added to across the 12v feed to the fans (take care of the polarity if it is an electrolytic & the voltage rating is 20v) - just like we had to fit on the ignition system on cars years ago.
I'd guess the cause of the interference is sparking from the brushes & commutator.
The other option is shorter wash/toilet usages!
oldbloke said
07:19 PM Jan 8, 2019
Thanks Warren,
Van is in storage so will look at the option of fitting a capacitor in a few weeks. See what's involved.
Is this a common issue?
So putting a filter on the TV arial won't work?
oldbloke said
07:22 PM Jan 8, 2019
Thanks Warren, yep, I guessed it was the brushes.
Van is in storage so will look at the option of fitting a capacitor in a few weeks. See what's involved.
Is this a common issue?
So putting a filter on the TV arial won't work?
Warren-Pat_01 said
10:36 PM Jan 8, 2019
Neil,
A filter on the TV aerial? It might but I'm not certain what is available or at what cost. You'd need a High Pass Filter with the lowest frequency equal to the minimum TV channel.
PeterD might know if you can "wake him up" - he could be on holidays as I haven't seen any posts from him recently.
oldbloke said
06:07 PM Jan 9, 2019
Any other options?
Would it be possible to shield the motor?
Warren-Pat_01 said
10:03 PM Jan 9, 2019
Sounds like a lot of mucking around for not very much of a benefit - unless you're looking for a job & want to do some experimenting.
I'd try the capacitor first.
Possum3 said
08:36 AM Jan 10, 2019
oldbloke wrote:
Any other options? Would it be possible to shield the motor?
You could always replace the offending fan/motor with a better one. I am a screen addict but I wouldn't bother for a couple of minutes a day.
geoffmaree said
11:33 AM Jan 11, 2019
Ive heard a ferrite sleeve could fix the problem.
oldbloke said
01:08 PM Jan 11, 2019
Possum3 wrote:
oldbloke wrote:
Any other options? Would it be possible to shield the motor?
You could always replace the offending fan/motor with a better one. I am a screen addict but I wouldn't bother for a couple of minutes a day.
Yeh. The 2 exhaust fans normally only run for 10 minutes a day. Not a big deal. But the portable battery operated fan for hot weather is the real issue.. Run it for several hours at a time.
Possum3 said
09:45 AM Jan 13, 2019
By "Battery operated fan" Do you mean running on van's 12v system? If so the fan motor may need rewinding.
oldbloke said
05:42 PM Jan 14, 2019
The fan has its own batteries that can be charged from 240v or 12v. Even when operating from the internal batteries it causes the pixilizing.
It must be a brush type DC motor to give you interference.Does repositioning it well away from the tv reduce the problem?
If It does , can you access the actual motor? Is it metal or plastic encased?
oldtrack123 said
05:03 PM Jan 19, 2019
Possum3 wrote:
It seems the (cheap) 12V motors in bathroom exhaust fans create interference with most TV's using the same 12V system - If you can run the TV on 240V if in caravan park that may relieve the interference.
-- Edited by oldtrack123 on Saturday 19th of January 2019 05:05:38 PM
oldtrack123 said
05:06 PM Jan 19, 2019
oldbloke wrote:
One of these.
Does the problem only show up in weak signal areas or all the time ,no matter where located & what way the antenna is pointing.
Have you tried changing the direction of the Antenna so it points towards the nearest tv station. Another option could be a signal booster in the antenna feed line. Another cause could be a faulty coupling lead from arial outlet to TV.
oldbloke said
02:31 PM Jan 20, 2019
Thnx olddtrack. Ill try a few options next weekend
