I am considering installing a snorkel head and tube on my poptop caravan roof to a tube down into van to help with dust minimisation. Firstly ..is it safe enough to walk/crawl on roof on a builders plank..ie...will the side walls of the poptop be strong enough to carry the weight (I am 105 KG). And secondly....how do I determine where the frame cross beams are that are in the roof for support ???
The van is a very late 2017 Jayco Journey 17.55.8 Poptop. Would like to see pics if possible Please.
TIA.
Cheers Keith
landy said
09:45 PM Jun 2, 2019
If it was me Kieth and seeing that the van is fairly new I would be consulting Jayco as to the roof suporting your weight and cutting the hole in the roof. Landy
Warren-Pat_01 said
11:07 PM Jun 2, 2019
Keith,
I'd be very careful. I know the frame around the edges of the lift up lid is quite strong but as to what's in between, I don't now. One thing I'd like to do is visit the Jayco factory in Melbourne & take pictures if that is allowed. I know there isn't much in the roof above the internal lights!! Just two thin pieces of f-glass & some el cheapo insulation wool. I think the roof of my Discovery would be similar to yours.
I want to use a sorkel head on the roof with the washable filter that is available for them. A scupper vent is available I know...but no amount of designing or thinking outside the square ideas are available to me to install some sort of filtration to stop dust. Have already had one van fitted with a scupper vent .....no bloody good IMO.
Cheers Keith9
Bas + Eve said
03:50 PM Jun 3, 2019
I have been told Jayco have a very thin lay up on the roof and not meant to be walked on. I guess a lot depends on your weight too
stevep1 said
04:44 PM Jun 3, 2019
Hi Keith,
we have the same van (2014) and I would also like to install a 'pressure vent'.
I have been on the roof many times ( cleaning, extra solar install, reseal hatch ) but use a painters plank, on top of pieces of 90*35 placed on the roof edge, so that the plank does not touch the roof and the outer beam supports any weight.
Where are you going to install the vent, would appreciate pictures of the finished job.
Cheers, Steve
STRETCH ARMSTRONG said
06:33 PM Jun 3, 2019
If l was doing it l would put a filter in the front trunk, ducted into van. Then do a snorkle up the front on one side of the van with the head at desired height. Just a thought.
Keith P said
08:06 PM Jun 4, 2019
STRETCH ARMSTRONG wrote:
If l was doing it l would put a filter in the front trunk, ducted into van. Then do a snorkle up the front on one side of the van with the head at desired height. Just a thought.
Well...you aint doing it .and I am. I needed to know some information on roof supporting my weight....and how to locate the various beams and trusses that I know make up the poptop roof. The process that I want to use has been the result of more than a few hours of finding out which way to go about this....simple and I believe....from research I have done....to be effective. On top of that ...I don't want to jam anymore fixtures in my boot...I need that part of van for other duties !!
I am a bit sorry I asked for info on here....as everyone seems to think I need to know this or that or some other GUMPH about stuff that really has nothing to do with what I actually asked about. So for those that may know about my query...please help me out here folks.....
Cheers Keith
-- Edited by Keith P on Tuesday 4th of June 2019 08:09:58 PM
Yep...your right about that....and I already know a little bit about that side of it.....so I,m trying to find out stuff that I don't know about.
Cheers Keith
Aus-Kiwi said
08:00 AM Jun 5, 2019
I would use a section of plywood to spread my weight . Its not exactly the weight its the concentration in one area. Check area under roof where theres support ? Possibly lean over from ladder if right hight ? Spreading your weight ?
deverall11 said
11:50 AM Jun 5, 2019
Keith P wrote:
STRETCH ARMSTRONG wrote:
If l was doing it l would put a filter in the front trunk, ducted into van. Then do a snorkle up the front on one side of the van with the head at desired height. Just a thought.
Well...you aint doing it .and I am. I needed to know some information on roof supporting my weight....and how to locate the various beams and trusses that I know make up the poptop roof. The process that I want to use has been the result of more than a few hours of finding out which way to go about this....simple and I believe....from research I have done....to be effective. On top of that ...I don't want to jam anymore fixtures in my boot...I need that part of van for other duties !!
I am a bit sorry I asked for info on here....as everyone seems to think I need to know this or that or some other GUMPH about stuff that really has nothing to do with what I actually asked about. So for those that may know about my query...please help me out here folks.....
Cheers Keith
Gee Keith, would've thought by now that you would realise for every well intended question there will always be at minimum one well meaning person
wanting to tell you what to do and how to do it.
My opinion.
Larry
-- Edited by Keith P on Tuesday 4th of June 2019 08:09:58 PM
T1 Terry said
02:55 PM Jun 5, 2019
:lol: Love it. We have to climb on van roofs all the time. I use a kneeling mat that is a bit like a plastic tea service tray with closed cell foam in it for the spot I'm working on to spread the weight and bits of form ply across the softer roofs to work my way across to where I need to work. Crawling on hands and knees spreads the weight enough combined with the form boards and kneeling pad to climb on any roof that is strong enough to hold up a roof top rattler air con, but no real idea about a poptop roof.
I'm assuming you would have it in the closed position when you wish to climb on it, so form board as big as you can fit to spread the load should be fine. I recommend the kneeling pad, it doesn't take long for the knees to really arc up and make it near impossible to crawl back off the roof and down the ladder.
If you are really worried about your weight on the roof, a couple of painters A frames each side and a painters plank across the roof or portable scaffolding so you don't put any weight at all on the roof.
The simple hand press on the roof will indicate where the bearers are so that part is reasonably easy.
T1 Terry
Keith P said
08:52 PM Jun 5, 2019
T1 Terry wrote:
:lol: Love it. We have to climb on van roofs all the time. I use a kneeling mat that is a bit like a plastic tea service tray with closed cell foam in it for the spot I'm working on to spread the weight and bits of form ply across the softer roofs to work my way across to where I need to work. Crawling on hands and knees spreads the weight enough combined with the form boards and kneeling pad to climb on any roof that is strong enough to hold up a roof top rattler air con, but no real idea about a poptop roof. I'm assuming you would have it in the closed position when you wish to climb on it, so form board as big as you can fit to spread the load should be fine. I recommend the kneeling pad, it doesn't take long for the knees to really arc up and make it near impossible to crawl back off the roof and down the ladder. If you are really worried about your weight on the roof, a couple of painters A frames each side and a painters plank across the roof or portable scaffolding so you don't put any weight at all on the roof. The simple hand press on the roof will indicate where the bearers are so that part is reasonably easy.
T1 Terry
Hooray !!! At last ...some info I can use ...thanks Terry. As luck would have it .a builder mate of mine offered his trellis ladders and a 5 metre builders plank this morning....plus help in identifying roof bearers with his stud finder....but I reckon your method ( which had not even got within a bull,s roar of entering my brain ) will probly be close to the mark....
He also has a gizmo that detects current inside walls ...but was unsure if it works on 12 volt...so we will see. Now all I have to do is gather all the bits together ...and do it.
Cheers Keith
-- Edited by Keith P on Wednesday 5th of June 2019 08:58:13 PM
Keith P said
08:56 PM Jun 5, 2019
deverall11 wrote:
Keith P wrote:
STRETCH ARMSTRONG wrote:
If l was doing it l would put a filter in the front trunk, ducted into van. Then do a snorkle up the front on one side of the van with the head at desired height. Just a thought.
Well...you aint doing it .and I am. I needed to know some information on roof supporting my weight....and how to locate the various beams and trusses that I know make up the poptop roof. The process that I want to use has been the result of more than a few hours of finding out which way to go about this....simple and I believe....from research I have done....to be effective. On top of that ...I don't want to jam anymore fixtures in my boot...I need that part of van for other duties !!
I am a bit sorry I asked for info on here....as everyone seems to think I need to know this or that or some other GUMPH about stuff that really has nothing to do with what I actually asked about. So for those that may know about my query...please help me out here folks.....
Cheers Keith
Gee Keith, would've thought by now that you would realise for every well intended question there will always be at minimum one well meaning person
wanting to tell you what to do and how to do it.
My opinion.
Larry
-- Edited by Keith P on Tuesday 4th of June 2019 08:09:58 PM
Yep ...your right ...I should have known.....but what a bloody waste of time and energy hey. Still gets up my nose but ...and I bet I,m not the only one either. Will know better in the future...if there is a next time....
I am considering installing a snorkel head and tube on my poptop caravan roof to a tube down into van to help with dust minimisation. Firstly ..is it safe enough to walk/crawl on roof on a builders plank..ie...will the side walls of the poptop be strong enough to carry the weight (I am 105 KG). And secondly....how do I determine where the frame cross beams are that are in the roof for support ???
The van is a very late 2017 Jayco Journey 17.55.8 Poptop. Would like to see pics if possible Please.
TIA.
Cheers Keith
I'd be very careful. I know the frame around the edges of the lift up lid is quite strong but as to what's in between, I don't now. One thing I'd like to do is visit the Jayco factory in Melbourne & take pictures if that is allowed. I know there isn't much in the roof above the internal lights!! Just two thin pieces of f-glass & some el cheapo insulation wool. I think the roof of my Discovery would be similar to yours.
A Scupper Vent (see www.caravanningwithkids.com.au/what-is-a-scupper-vent/) is what you need, I believe. Read the comments under the "Shop" section. This site www.rgdcorp.com.au/products/marine/scupper-vents/ shows the various sizes of them.
Thanks for the replies so far.
I want to use a sorkel head on the roof with the washable filter that is available for them. A scupper vent is available I know...but no amount of designing or thinking outside the square ideas are available to me to install some sort of filtration to stop dust. Have already had one van fitted with a scupper vent .....no bloody good IMO.
Cheers Keith9
we have the same van (2014) and I would also like to install a 'pressure vent'.
I have been on the roof many times ( cleaning, extra solar install, reseal hatch ) but use a painters plank, on top of pieces of 90*35 placed on the roof edge, so that the plank does not touch the roof and the outer beam supports any weight.
Where are you going to install the vent, would appreciate pictures of the finished job.
Cheers, Steve
-- Edited by Keith P on Tuesday 4th of June 2019 08:09:58 PM
Cheers,
Peter
Yep...your right about that....and I already know a little bit about that side of it.....so I,m trying to find out stuff that I don't know about.
Cheers Keith
I'm assuming you would have it in the closed position when you wish to climb on it, so form board as big as you can fit to spread the load should be fine. I recommend the kneeling pad, it doesn't take long for the knees to really arc up and make it near impossible to crawl back off the roof and down the ladder.
If you are really worried about your weight on the roof, a couple of painters A frames each side and a painters plank across the roof or portable scaffolding so you don't put any weight at all on the roof.
The simple hand press on the roof will indicate where the bearers are so that part is reasonably easy.
T1 Terry
Hooray !!! At last ...some info I can use ...thanks Terry. As luck would have it .a builder mate of mine offered his trellis ladders and a 5 metre builders plank this morning....plus help in identifying roof bearers with his stud finder....but I reckon your method ( which had not even got within a bull,s roar of entering my brain ) will probly be close to the mark....
He also has a gizmo that detects current inside walls ...but was unsure if it works on 12 volt...so we will see. Now all I have to do is gather all the bits together ...and do it.
Cheers Keith
-- Edited by Keith P on Wednesday 5th of June 2019 08:58:13 PM
Quite sad actually.
agree
